Lampholder G5 for G5 Push-In Lampholders
品番:
26.662.2011-0
EAN:
-
-
-
-
0,6 - 1,0
-
-
-
-
-
製品情報 "Lampholder G5 for G5 Push-In Lampholders"
Wiring above the mounting plate is also possible
Snap in pins for IP 40
A pair of lampholders provides a lamp length tolerance compensation of 2 mm
Snap in pins for IP 40
A pair of lampholders provides a lamp length tolerance compensation of 2 mm
| Ausführung: | G5 Push-In Lampholders |
|---|---|
| Color: | white |
| Lamp axis height: | 15 |
| Luminaire wall thickness: | 0.6 - 1.0 |
| Material: | Housing: PCRotor: PBT |
| Note warranty conditions: | *Warranty conditions of BJB GmbH & Co. KG as stated as available via the Internet under https://www.bjb.com/en/legal-information/general-terms-and-conditions/ are valid. |
| Packaging quantity: | 1000 |
| Producttype: | G5 Push-In Lampholders |
| Series: | Linear Fluorescent Lampholders for dry rooms (IP20) |
| UL: | yes |
| Weight: | 3 g |
| Wiring: | through the body |
| cULus file no.: | E-92235 |
| mounting method 1: | Push-in pins |
| old article number: | 26.662.2011.50 |
利用可能なダウンロード
Available CAD Downloads
認証
| 品番 | スターテス | 説明 | 書類 |
|---|---|---|---|
| 26.662.2011-0 | CQC_Genehmigung_liegt_vor_--CQC_approval_at_hand_-1193791 | ||
| 26.662.2011-0 | IRAM_Genehmigung_liegt_vor_--IRAM_approval_at_hand_-749651 | ||
| 26.662.2011-0 | ENEC_Zeichen_--ENEC_Approval_-713266 | ||
| 26.662.2011-0 | PSE-Mark_(Japan)--1206225 | ||
| 26.662.2011-0 | Genehmigung_liegt_vor_--Approval_at_hand_-2667527 | ||
| 26.662.2011-0 | cULus_(USA_and_Kanada)--727851 | ||
| 26.662.2011-0 | EAC_Genehmigung_liegt_vor_--EAC_approval_at_hand_-3677956 |
-
-
-
0,6 - 1,0
-
-
-
-
-
